Rotunbot RT-G800 Intelligent Amphibious Spherical Robot

The Rotunbot RT-G800 is a next-generation intelligent amphibious spherical robot designed for long-duration operations in complex terrain, extreme weather, and non-friendly environments. Built around a unique spherical contour and centroid offset drive system, Rotunbot represents a breakthrough in unmanned ground robotics, offering unmatched stability, endurance, and all-weather operational capability where conventional wheeled or legged robots fail.

Engineered for demanding applications such as civil aviation airports, public security, armed police operations, energy infrastructure inspection, and emergency response, the RT-G800 delivers a reliable, autonomous solution for continuous patrol, monitoring, and intervention tasks. Its sealed spherical design, high-speed rolling mobility, and advanced sensor fusion allow it to operate safely in rain, snow, sand, fog, extreme temperatures, and hazardous environments with minimal human risk.

Revolutionary Spherical Mobility and Drive Architecture

At the core of the Rotunbot RT-G800 is its patented spherical structure combined with pendulum-based centroid offset drive technology. Three internal motors drive a pendulum mechanism that shifts the robot’s center of mass, generating rolling torque in any direction.

This design fundamentally eliminates common failure points seen in wheeled and legged robots, such as tipping, rollover, and immobilization after impact. The robot can roll freely in all directions, recover automatically after collisions, and maintain operational continuity even in uneven or unpredictable terrain.

The rolling motion significantly reduces friction and energy loss, enabling energy efficiency 5–6 times higher than legged robots, while also delivering exceptional speed and responsiveness.

High-Performance Motion and Endurance

The RT-G800 is designed for extended missions and rapid response scenarios:

• Instantaneous maximum speed of up to 35 km/h

• Cruising speed of approximately 18 km/h

• Acceleration to top speed in about 2.5 seconds

• Maximum climbing angle of 22 degrees

• Ability to overcome 300 mm vertical obstacles

• Continuous operation time of 8 hours or more on a single charge

• Maximum range exceeding 100 km per charge

Its terrain adaptability allows stable operation on hardened roads, grasslands, sandy surfaces, slopes, beaches, deserts, and uneven ground with surface fluctuations of 3–6 cm.

All-Weather and Extreme Environment Capability

The Rotunbot RT-G800 is built to operate where humans and traditional robots cannot:

• IP68 fully sealed spherical shell for dustproof and waterproof performance, including long-duration submersion

• Operational temperature range of –25°C to 65°C, with custom configurations supporting –45°C to 85°C

• Resistance to heavy rain, snowstorms, strong winds (up to grade 8), and hail impacts

• Ability to function in fog, haze, corrosive environments, radioactive zones, and flammable or explosive atmospheres for short durations

This makes the RT-G800 particularly suited for airports, oil fields, deserts, coastal zones, disaster areas, and industrial hazard zones.

Comprehensive Safety and Security Architecture

Safety is integrated at every level of the system:

Battery and Power Safety

• High-safety ternary lithium or semi-solid lithium battery

• Battery sealed within a thick lead pendulum enclosure

• Thermal failure temperature exceeding 120°C

• Extremely low electrolyte leakage probability

• Certified to military-grade safety standards

Communication Security

• Standard 4G, Wi-Fi, and Ethernet connectivity

• Optional backpack relay station and shortwave radio modules

• AES-256 end-to-end encryption with automatic key updates

• Frequency hopping and multipath suppression for stable communication

• Communication success rate above 99.5 percent in complex electromagnetic environments

Operational Safety

• Three-level electronic geofencing system with authorized, restricted, and prohibited zones

• Automatic stop when entering restricted areas

• Real-time cloud monitoring with emergency intervention and forced shutdown capability

Advanced Sensors and Intelligent Perception

The RT-G800 integrates a robust sensor suite for full situational awareness:

• Laser radar with precise ranging, speed measurement, and obstacle detection

• Wide-angle HD camera supporting 360-degree panoramic vision and real-time video backhaul

• Beidou GPS with RTK enhancement for accurate positioning and velocity tracking

• Acoustic wave disperser capable of producing high-intensity directional sound

• Environmental audio pickups with abnormal sound recognition and reporting

These systems enable autonomous navigation, anomaly detection, intrusion monitoring, and adaptive response in real time.

Core Functional Capabilities

• Autonomous patrol with dynamic path planning

• Flexible scheduling based on time, location, and threat conditions

• Multi-modal bird repelling using sound, visual deterrents, and environmental intervention

• Perimeter intrusion detection for personnel and vehicles

• Support for non-lethal tactical payloads such as net launchers, trip devices, and smoke systems

• Emergency response modes for weather events, communication loss, or mechanical damage

Typical Application Scenarios

Airports

• Bird strike prevention

• Runway and perimeter patrol

• Reduced manual patrol costs and improved aviation safety

Public Security and Armed Police

• Urban patrols and crowd control

• Anti-terrorism and stability operations

• Non-lethal engagement and reconnaissance in high-risk areas

Energy and Infrastructure

• Oil and gas pipeline inspection

• Leak detection and theft prevention

• Desert and remote terrain monitoring

Emergency and Disaster Response

• Fire scene reconnaissance

• Disaster area patrol in earthquakes, floods, and extreme weather

• Reduced risk to first responders

Certifications and Technology Credentials

• ISO-9001 Quality Management System certification

• ISO-14001 Environmental Management System certification

• MSDS-certified battery system

• Multiple global invention patents covering spherical motion and drive technology

• Recognized as a national technology-based enterprise
